Basic Info.
Model NO.
DC24RT50BL
Signal
Continuous
Function
Automatic Control, Protection
Certification
ISO: 9001, CE
Condition
New
Customized
Customized
Material
PCB
Volt
24/48VDC
Current
50A
Weight
1 Kg
Warranty
1 Year
Transport Package
Carton
Specification
148*117*40mm
Trademark
ZHIBI
Origin
China
HS Code
9032899090
Production Capacity
100000/Year
Packaging & Delivery
Package Size
20.00cm * 20.00cm * 15.00cm
Package Gross Weight
1.000kg
Product Description
24V 4Q Reversible Brake DC Motor Speed Controller
| Model | DC24RT50BL |
| Volt | 24VDC |
| Rated current | 30A |
| Max current | 50A |
| work mode | Speed mode |
| Control mode | 0-10V,0-5V,potentiometer |
| Protection | over current,over voltage |
| Suitable | brushed pm dc motor |
| Temperature | -10ºC-- +60ºC |
| Weight | 0.9kg |
| D imension | 135*135*70 mm |
| Application | EQUIPMENTS |
| 1. PULSE WIDTH MODULATION Motor runs quieter, with greater efficiency and less maintenance, longer life. |
| 2. FOUR QUADRANT REVERSIBLE OPERATION |
| 3. REGENERATIVE BRAKING No contactors required. No electromechanical components to overheat or wear out. |
| 4. ENABLE / BRAKE / DIRECTION TERMINALS Choose a function by simply opening or closing a dry contact or through an open collector transistor. |
| 5. STATUS LEDs Power and Fault LEDs provide a visual status of the drive. |
| 6. Forward and reverse can be set separately |
| 7. Output current can be set |
| 8. Braking current can be set |
| 9. Torque compensatio |
| 10. Standard analog control mode: Analog:0-5V or potentiometer |
| 11. Over voltage & less voltage protection |
| 12. OVER TEMPERATURE PROTECTION Drive will fold the output power back to prevent from overheating. Drive will fault if it still remains too hot. |
Reled Products:
| Model | Rated volt/V | Rated current | Max current | Controller mode | Regeneration | |
| DC24RT10BL | 12/24/48 | 5A | 10A | Potentiometer, PWM, 0-5V | Yes | |
| DC24RT15BL | 12/24/48 | 8A | 15A | Potentiometer, PWM, 0-5V | yes | |
| DC24RT30BL | 12/24/48 | 15A | 30A | Potentiometer, PWM, 0-5V | Yes | |
| DC24RT50BL | 12/24/48 | 25A | 50A | Potentiometer, PWM, 0-5V | Yes | |
| DC24RT100BL | 12/24/48 | 50A | 100A | Potentiometer, PWM, 0-5V | Yes |
- Standard export carton with sponge
- Size : base on the order
- Weight : base on the order
- Detail data will be confirmed before shipping
| Pre-service | After Sales Service |
| Inquiry and Consult Support Sample testing Support View our Factory | Help instal and use the product 24 hours online problem solving |
