Basic Info.
Model NO.
DK7732ZB
Movement Method
Contour Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.015mm
Performance Classification
Economical CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Table Size (Wxd)
440*680
Table Travel (Xxy)
320*400
Table Travel (Uxv)
140*140
Max. Workpiece Weight
600
Transport Package
Wooden Cases
Specification
1765*1170*2150 1500kg
Trademark
TOPSCNC
Origin
Taizhou, Jiangsu, China
HS Code
8456301090
Production Capacity
100sets/ Month
Product Description
Product description
Product details image
Why choose us
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q. Could your engineers go to our factory to install the machine and train our workers?
A:Yes, our engineers could go to your factory and assist you.
Q:What is your warranty?
A:One year after shipment ,consumables are not included.
Q: What is your terms of payment ?
A:L/C or T/T before shipment.
Contact us
Company: Jiangsu Dongqing CNC Machine Tool Co. Ltd.
Address: East Suburb Development Zone, Taizhou city, Jiangsu Province, China
Tel: 0086-523-86290115
Mobile: 0086-15751152221
Web: topscnc.en.made-in-china.com
| Technique parameters | Unit | DK7732ZB |
| Table size (WxD) | mm | 440×680 |
| Table travel (XxY) | mm | 320×400 |
| Table travel (UxV) | mm | 140×140 |
| Z-axis control | manual control | |
| Z-axis guideway | slide guides | |
| Max. workpiece weight | kg | 600 |
| Thickness of workpiece | mm | 350 |
| Max.taper angle | ±15°/80mm | |
| Diameter of cutting wire | mm | φ0.15~φ0.20mm(recommendφ0.18mm) |
| Feeding speed | m/sec | 1~11.4m/sec adjustable |
| Precision | mm | ≤0.015 |
| Machining speed | mm²/min | >200 |
| Surface roughness | μm | Ra≤2.5 |
| Motor type | X,Y,U,V stepper motor | |
| Control axis | 4 axis simultaneous | |
| Min. control pace | mm | 0.001 |
| Power supply | 3N-380V/50Hz | |
| Max. working current | A | 12 |
| Power consumption | Kw | 1 |
| Working liquid | JA-1 | |
| Water tank | L | 55 |
| Filtering mode | filter screen | |
| Control System | Auto-cut | |
| Machine weight | kg | 1500 |
| Machine dimensions | mm | 1765×1170×2150 |
